Operation

1. Rotate the ON/OFF dial switch to power the camera. The power indicator on the top of the
handle will switch on.
2. Further rotation of the switch adjusts the intensity of the two LEDs on the camera head.
3. Slide the On/Off switch on the side of the monitor to the ON position
4. Press the power button on the face of the monitor. The power light will turn on and the picture
will appear.
5. Press the orientation button on the face of the monitor to rotate the picture as needed.
6. Press the brightness and contrast buttons in conjunction with the rotating the LED intensity for
the best image quality.
7. The tube can be easily maneuvered into position. The tube can be bent into the shape of the
area to be examined.
8. Use the supplied accessories to help retrieve small items.
Charging the Meter
1. Place batteries into the handle of the meter.
2. Attach the monitor to the handle and slide the ON/OFF switch on the side of the meter to
OFF.
3. Rotate the ON/OFF dial to power the camera. The power indicator on the top of the handle
will switch ON.
4. The battery power from the handle will charge the monitor.
5. To save battery power: while charging the meter, remove the cable from the handle. This
prevents the LEDs from lighting and consuming additional power.

Specifications

CAMERA
Imaging Sensor
Total Pixels
Horizontal View Angle
Transmission Frequency
Minimum Illumination
Power Supply
LCD Screen Type
Effective Pixels
Video Output Level
Receiving Sensitivity
Dimensions (Monitor)
Operating Humidity (Max.)
Waterproof Capacity
Dimensions (Handle)
Weight (approx)
Camera head Diameter
Operating Temperature
www.ponpe.com
CMOS
712×486 (NTSC)
50 degree
2468MHz
0 Lux
4 x AA batteries
2.36" TFT-LCD
480 x 234
0.9-1.3VP-P@75Ώ
≤-85dBm
(W x D x H) 3.9 x 2.8 x 1.2" (100 x 70 x 30mm)
15~85%RH
IP67 (imager head only)
(W x D x H) 7.3 x 5.7 x 1.6" (186 x 145 x 41mm) (Excluding
Flexible Tube)
15.5 oz. (440g)
0.67" (17mm)
+14°F~+122°F (-10°C~+50°C)
