Operation
1. Press the power switch to turn the camera ON, the power indicator lights and the image displays
on the LCD.
2. Insert the camera head and the flexible cable into the area to be viewed. Pre‐shape the cable
when inserting into areas with bends and curves.
3. Image adjustments
LED intensity:
Two LEDs mounted next to the camera are used to illuminate the inspection area. Press the
LED button to step through the six levels of intensity (lowest to highest). A seventh press turns
the LEDs off.
LCD Contrast Control:
There are 8 levels of LCD contrast. Press the LCD Contrast Control button to adjust the
contrast, Press the button to increase the contrast, at the highest level it will return to the
lowest level. When in use, the tube should easily maneuver itself into position going
forward.
Picture Rotation:
Press the button to flip the image. The figure to the right demonstrates how
the image is adjusted for each button press.
Warning. Permanent damage to the flex tube and loss of operation will occur if the flex tube is
subjected to narrow radius or sharp angle bends.
www.ponpe.com
5
ROTATE
R O T A T E
E T A T O R
