6.0.6 Using MPUIQ-SRL Modules

An administrator can choose between the ACS console server and Cisco® pinouts for each MPUIQ-SRL
serial port via the local user interface or the remote OBWI. ACS is the default.
To change the pinout to Cisco mode:
1. Select Unit View - Appliance - Appliance Settings - Ports - RIPs.
2. Click on the desired RIP.
3. Select Settings - Pinout.
NOTE: If the DB9 adaptor is used, select the ACS console server pinouts.

6.0.7 ACS console server port pinouts

The following table lists the ACS console server serial port pinouts for the MPUIQ-SRL module.
Table 5.2 ACS Console Server Serial Port
Pinouts
PIN NO. SIGNAL NAME
1 RTS - Request to Send
2 DTR - Data Terminal Ready
3 TXD - Transmit Data
4 GND - Signal Ground
5 CTS - Clear to Send
6 RXD - Receive Data
7 DCD/DSR - Data Set Ready
8 N/C - Not Connected

6.0.8 Cisco port pinouts

The following table lists the Cisco serial port pinouts for the MPUIQ-SRL module.
Table 5.3 Cisco Serial Port Pinouts
PIN NO. SIGNAL NAME
1 CTS - Clear to Send
2 DCD/DSR - Data Set Ready
3 RXD - Receive Data
4 GND - Signal Ground
5 N/C - Not Connected
6 TXD - Transmit Data
7 DTR - Data Terminal Ready
Vertiv™ | Vertiv™ Avocent® MergePoint Unity™ Switch for Dell® Installer/User Guide |
INPUT/OUTPUT
OUT
OUT
OUT
N/A
IN
IN
IN
N/A
INPUT/OUTPUT
IN
IN
IN
N/A
N/A
OUT
OUT
