ICON CONTROL
Return To
Start
Skip Back
Play
Pause
Recording
Stop/Start
Fast
Forward
Go To End
Live
Slider
Exporting video
You can create a video from a source file on the host and then export it to the client machine.
To export video:
1. Select Tools - Export Video from the KVM Videw Viewer menu.
2. Browse for the source file.
3. Browse for the exported file.
4. Use the drop-down menu to select the resolution.
5. Click Export.
Vertiv™ | Vertiv™ Avocent® MergePoint Unity™ Switch for Dell® Installer/User Guide |
DESCRIPTION
When a persistent file is being played, clicking this button will cause the playback to move back to the start of the file. When a
session is being recorded, clicking this button will cause the continuous recording buffer to go to its oldest data and start
playing back from that point.
When a file or continuous recording is being played, clicking this button will cause the play position to go back one 30-second
period at a time. Each time it is clicked, the play position will move back to the start of the previous period. If the playback
mode was Play or Fast Forward when this button was clicked, the playback will proceed at a speed of 1X. If the playback
mode was Paused when this button was clicked, the playback will display the first frame of the previous period. If the
continuous recording buffer reaches the play position, then playback will proceed at a speed of 1X.
Click this button to play the recording.
While a file is being played, the Play button becomes the Pause button. Click it to pause the playback. During a Live session,
clicking the Pause button will pause the Live playback. Live mode will change to Continuous and the Play button will be
disabled.
Click this button to open the Save dialog box. Use the drop-down menu to choose a location to save the recording. Once
you've entered a filename and clicked Save, the recording will begin. While recording, click the button again to stop the
recording.
During playback, click this button to fast forward one 30-second period at a time. Each time this button is clicked, the
playback rate will increment by 10:1 until the fifth time it is clicked. The fifth time it is clicked will return the playback rate back
to 10X.
When this button is clicked, the file or continuous recording that is being played back will go to the end of the recording. When
a file is not being played but a KVM session is in progress, clicking this button will display the live video from the connected
KVM session.
When this button is clicked, it will terminate the playback of a file or a continuous recording and display the video from the
connected KVM session. If there is no connected KVM session (such as a file was being played back without a connected
KVM session, or the KVM session has terminated), then this button will be disabled and grayed out.
The slider at the bottom of the screen displays the progress of the playback in the context of the overall length of the file or
continuous recording. It will act like a scrollbar in that the thumb will move from left to right as the recording is played back. If
the video is paused and you click or drag the slider, it will move to that position and remain paused. If video is playing and you
click or drag the slider, it will move to that position and continue playing.
