3.16 Configuring IQ Modules

From the Appliance IQ Modules screen, you can display a list of the attached IQ modules, as well as the
following information about each IQ module: EID, Port, Status, Application, Interface Type and USB Speed.
You can click on one of the IQ modules to view the following additional information: Switch Type, Boot
Version, Hardware Version, FPGA Version, Version Available and Upgrade Status
You can also perform the following tasks: delete offline IQ modules, upgrade the IQ module firmware, set
the USB speed or decommission the IQ module.
To delete offline IQ modules:
1. From the side navigation bar, click Unit View - Appliance - ApplianceSettings - Ports - IQ
Modulesto open the Appliance IQ Modules screen.
2. Click Delete Offline.
To set the IQ module USB Speed (for DSAVIQ-USB2 modules only):
1. From the side navigation bar, click Unit View - Appliance - ApplianceSettings - Ports - IQ
Modulesto open the Appliance IQ Modules screen.
2. Select the checkbox(es) next to the IQ module(s) that you wish to modify.
3. Click either Set USB 1.1 Speed or Set USB 2.0 Speed.

3.16.1 Upgrading IQ modules

The IQ module Flash upgrade feature allows appliance administrators to update IQ modules with the
latest firmware available. This update can be performed using the switch user interfaces or DSView™
software.
After the Flash memory is reprogrammed with the upgrade, the switch performs a soft reset, which
terminates all IQ module sessions. A target device experiencing an IQ module firmware update may not
display, or may display as disconnected. The target device will appear normally when the Flash update is
completed.
IQ modules are automatically updated when the switch is updated. To update your switch firmware, see
Appliance Tools on page 21 or the DSView Software Online Help. If issues occur during the normal
upgrade process, IQ modules may also be force upgraded when needed.
NOTE: Check http://www.VertivCo.com for firmware upgrade files.
To upgrade the IQ module firmware:
1. From the side navigation bar, click Unit View - Appliance - ApplianceSettings - Ports - IQ
Modulesto open the Appliance IQ Modules screen.
2. Select the checkbox(es) next to the IQ module(s) that you wish to upgrade and click Upgrade.
