Appendix F: Technical Specifications

Table 5.7 Technical Specifications
CATEGORY VALUE
Server Ports
MPU8032DAC/8032/4032DAC/4032/2032DAC/2032: 32 MPU2016DAC/2016/1016DAC/1016: 16 MPU108EDAC/108E: 8
Number
MPU104E: 4
Type PS/2, Sun, USB and Serial
Connectors 8-pin modular
Sync Types Separate horizontal and vertical
Input Video Standard 640 x 480 @ 60 Hz 800 x 600 @ 75 Hz 960 x 700 @ 75 Hz 1024 x 768 @ 75 Hz 1280 x 1024 @ 75 Hz 1600 x 1200 @ 60 Hz
Resolution Wide-screen 800 x 500 @ 60 Hz 1024 x 640 @ 60 Hz 1280 x 800 @ 60 Hz 1440 x 900 @ 60 Hz 1680 x 1050 @ 60 Hz
Supported
4-pair UTP CAT 5 or CAT 6, 45 meters maximum length
Cabling
Dimensions
Form Factor 1 U-rack, mountable
16 and 32 port
models 4 and 8 1.72 x 17.00 x 13.38 (Height x Width x Depth) 1.72 x 17.00 x 11.00 (Height x Width x Depth)
port models
Weight
(without MPU8032DAC: 8.6 lbs
cables)
SETUP Port
Number 1
Type RS-232 serial
Connector 8-pin modular
Local Port (4 and 8 port)
Number/Type 1 VGA/4 USB
Local Port (16 and 32 port)
Number/Type 1 VGA/5 USB
Network Connection
Number 2
Type 10/100/1000 Ethernet
Connector 8-pin modular
USB Device Port
Number 4 (4 and 8 port) or 5 (16 and 32 port)
Type USB 2.0
MODEM Port
Number 1
Type RS-232 serial
