4. After the success screen appears, click Close. Reboot the managed appliance to enable the
restored configuration. See

3.5 Network Settings

NOTE: Only Appliance Administrators can make changes to Network dialog box settings. Other users
will have view only access.
To configure general network settings:
1. From the side navigation bar, select Unit View - Appliance - Appliance Settings - Network -
General. The Appliance General Network Settings screen appears.
2. Select one of the following options from the LAN Speed drop-down menu: Auto-Detect, 10
Mbps Half Duplex, 10 Mbps Full Duplex, 100 Mbps Half Duplex, 100 Mbps Full Duplex or 1 Gbps
Full Duplex.
NOTE: You must reboot if you change the Ethernet mode.
3. Select either Enabled or Disabled in the ICMP Ping Reply drop-down menu.
4. Click Save.
To configure IPv4 network settings:
1. From the side navigation bar, select Unit View - Appliance - Appliance Settings - Network -
IPv4. The Appliance IPv4 Settings screen appears.
2. Select or deselect the Enable IPv4 checkbox to enable or disable IPv4 mode.
3. Enter the desired information in the Address, Subnet and Gateway fields.
4. Select either Enabled or Disabled in the DHCP drop-down menu.
NOTE: If you enable DHCP, any information that you enter in the Address, Subnet and Gateway fields
will be ignored.
5. Click Save.
To configure IPv6 network settings:
1. From the side navigation bar, select Unit View - Appliance - Appliance Settings - Network -
IPv6. The Appliance IPv6 Settings screen appears.
2. Select or deselect the Enable IPv6 Stateful Configuration checkbox to enable or disable.
3. Enter the desired information in the Address, Gateway and Prefix Length fields.
4. Select either Enabled or Disabled in the DHCPv6 drop-down menu.
NOTE: If you enable DHCPv6, any information that you enter in the Address, Gateway and Prefix
length fields will be ignored.
5. Click Save.
Vertiv™ | Vertiv™ Avocent® MergePoint Unity™ Switch for Dell® Installer/User Guide |
Rebooting the switch on page 21.
