Logging out
A user may log out at any time by clicking the logout icon in the top option bar.

3.2 Viewing System Information

You can view various appliance and target device information from several screens in the user interface.
Table 3.3 System Information
CATEGORY
SELECT THIS:
Switch Unit View - Appliance - Overview
Unit View - Appliance - Properties
- Identity
Unit View - Appliance - Properties
- Location
Unit View - Appliance - Appliance
Settings - Versions
Unit View - Connections
Target Device Unit View - Target Devices
You will also be alerted if any of the following fault conditions occur: power supply failure (for switches
equipped with dual power supplies), elevated ambient temperature or fan failure. A yellow triangle with an
exclamation point and the name of the failure will appear in the header of each screen. This notification
will appear or disappear only after you refresh the page. You can click on the notification to get more
information.

3.3 Switch Sessions

From the Active Sessions screen, you can view a list of active sessions and the following information about
each session: Target Device, Owner, Remote Host, Duration and Type.

3.3.1 Launching a session

NOTE: Java 1.5.0_11 or later is required to launch a session when using a Linux or Mac operating
system.
To launch a session:
1. From the side navigation bar, select Unit View - Target Devices. A list of available devices will
appear.
2. Click the KVM Session or Serial Session link to the right of the desired target device to launch
the session.
Vertiv™ | Vertiv™ Avocent® MergePoint Unity™ Switch for Dell® Installer/User Guide |
TO VIEW THIS:
Name or type
Part number, serial number and EID
Site, department or location
Current firmware revision for application, boot and Video FPGA
List of the attached devices
List of connected target devices, as well as the following information about each device: Name,
Type, Status and Action
Click on one of the target devices to view the following additional information: Name, Type, EID,
available session option and the connection path
