① Display (LCD) : Shows the incubation environment.
③ Power adaptor connection socket :This socket allows power into to the device.
⑤ Down button : Used to select menu or to decrease value.
⑦ Candling button / Back button : Used to turn ON/OFF the candling function
or to go back to previous step in setup selections.
⑧ Candling zone : Used as candling device by pressing the Candling button.
Do not look directly into the LED light.
See Video on Icon's, Name's of buttons and Performance of function's

Explanation on Optional Functions

1. T.CAL (Temperature calibration)
2. H.CAL (Humidity calibration)
3. HI (Abnormal high temperature alarm)
4. LO (Abnormal low temperature alarm)
5. C/F (Celsius/Fahrenheit modification)
6. B.Lt (Back light setup)
7. In.L (Interior lighting setup)
8. Snd (Sound)
9. Info (Basic information)

2. BEFORE USE

What is Hatching room?

What is a hatching room? This is the location where the incubator is installed and operated. As the environment affects the hatching rate the place of
installation must be a place with low nearby noise or vibration, and nearby temperature must be 22~25℃ (71.6~77℉) with low temperature difference.
Especially in night time the temperature is lowered than daytime therefore it surely must be verified, and in daytime the device must never be exposed
directly under the sunlight. Also the place must not have direct ventilation as air conditioner to the device.
If the temperature of hatching room is lower than setup value there might be misted or dripping water inside due to dew condensation.
Rcom Bird Egg Incubator Eco Pro Plus 10 User Manual
Factory Defautlt Reset : The reset can be done by pressing 2 buttons at the same time for 1 seconds (only during incubation)
Option setup : The option can be setup by pressing 2 buttons at the same time for 3 seconds.
Menu selection / Egg rotation test / Setup value verification during incubation.
Increase value / 5 seconds : forcible pump operation / 10 seconds : forced pump operation for 2 minutes.
Decrease value / Termination of incubation.
While the button is pressed the candling function is turned on.
When setup menu : moves to previous step.
ICON Name and function
Chicken ↔
Pheasant ↔
Other birds ↔
Quail ↔
Duck
(according to above order)
Days until hatching
/ Shows Heater OFF/ON
/
Shows Humidification OFF/ON
/ Shows unit of Celsius / Fahrenheit
It is not recommendable direct adjustment by user. Please contact agent or supplier.
It is not recommendable direct adjustment by user. Please contact agent or supplier.
Sounds alarm when the incubator temperature is higher than setup value, due to external
environmental change or other anomaly.
0.0℃ ~ 5.0℃ [Default value : 2.0℃] modified by 1 degree unit.
Sounds alarm when the incubator temperature is lower than setup value due to external
environmental change or other anomaly.
0.0℃ ~ -5.0℃ [Default value : -3.0℃] modified by 1 degree unit.
Modification of Celsius (℃), Fahrenheit (℉) degrees
LCD back light ON/OFF/EVENT ON setup
Device's interior lighting ON/OFF setup
Device's button sound ON/OFF setup
Shows the basic information of this device. (Shows version information)
② Automatic Pumping System (APS) connection socket :
It is the socket which connects the APS to the device.
④ Up button : Used to select menu or to increase value.
⑥ Menu selection button : Button to save setup values.
ICON
[Default value : Celsius (℃)]
[Default value : ON]
[Default value : ON]
[Default value : ON]
Name and function
Shows operating Egg
rotation
Shows Egg rotation suspended
Shows Terminated Egg
rotation
Show Temperature /
Optional function
Shows humidity units
Shows humidity value
Shows blackout notification
(1) What is incubation room?
