Rcom Juragon PX-20R User Manual

1. Safety Cautions
Electrical hazards
Do not use a damaged Do not pull the cord when
power cord or loose taking out the power cord,
and keep wet hands away
outlet.
from connecting plug.
Risk of electric shock or fire. Risk of electric shock or fire.
Setting Cautions
Do not install in dusty or Do not install under the
dirty environment. direct sunlight.
Risk of damage or fire within Risk of fire or interference with
the incubator. the incubation process.
Do not cover the Install away from heat
ventilating opening. sources.
Inner temperature can rise, Risk of damage to the incubator
interrupting incubation. case and interference with
the incubation process.
Do not disassemble or Please ensure that no
modify the incubator in small objects get into
any way. the holes on the incubator.
Risk if electric shock or fire. Risk of electric shock or fire.
Cleaning Cautions
Do not spray cleanser Clean the incubator by a
directly on the incubator soft cloth with a neutral
surface. detergent.

2. Identification of Parts

Vents for air circulation
For circulating warm air
Air inlet vent
For inlet of air
from outside
View Window
For a clear view of
the incubation process.
( duplicated View Window )
Digital Control Center
See description of
the function and operation.
Locking Button
3. Basic Components
Main Body-2
Main Body-1
Water Cap
View Window
4. How to Assemble
Insert the power cord
View Window
in the socket at the back
of the main body.
Tray
Main Body-1
Main Body-2
Lock the three locking
buttons at the front and rear
of the incubator.
PX-20R
USER'S MANUAL
(Standard
Be careful the details below when you use.
Never pull the plug out of Do not twist or crush Do not insert multiple
the outlet during the electric cord. connecting plugs in an
incubation period. outlet.
Risk of fire or electrical overload.
Incubation will be interrupted. Risk of electric shock or fire.
Be careful the details below when you use.
Do not install in moist or Do not install in excessively Do not use any other
cold or hot conditions, non-standard parts
humid environment.
cigarette smoke, etc. except those provided.
Risk of fire or electric shock. Risk of interference with Risk of damage or hatching
the incubation process. failure.
Ensure that the incubator is Do not turn the incubator Do not install where
installed on a stable surface upside down. children or other people
away from edges. can touch with easy.
Risk of damage to incubator Water will pour out of the incubator, Risk of knocking the incubator
and eggs and user from and view window can be dropped or accidental interference with
accidental knocks or drops. or damaged. the controls.
If the incubator sounds Clean the incubator If the incubator requires
strange or emits smoke thoroughly before storing. repair disconnect from the
contact your service
power supply and please
center.
contact to your service center.
Risk of electric shock or fire.
Be sure to disconnect the electric cord
from the outlet before cleaning.
Brush away dust on the Do not use chemicals like wax, For special cleaning of
inner part per year, contact
plug with a dry cloth. benzene, alcohol, thinner,
to the service center.
aromatic, or lubricant, etc.
Power Connecting
(the rear)
For connecting
Tray for
power cord.
vermiculite( incubation sand)
and reptile eggs.
Main Body-1 Main Body-2
Power Cord
User's Manual
Tray
5. How to Replace Fuse
▶ When the machine failed to
power on even if you pluged in,
remove the fixing piece like
the picture by screwdriver.
▶ You can find assembled PCB
when open the cover.
Remove faulty fuse with screwdriver.
▶ Replace with new fuse.
( 250V 2.0A Ø5*20mm )

6. Before use

Digital Incubator
www.R-com.co.kr Environment conditions of the incubation room
for the installation of reptile incubator.
)
( Temp.: 22~25℃ / Humidity: 30~50% )
If the incubation room temperature does not meet
the required temperature, it can not be controlled
automatically with the set incubation conditions.
Room temperature should be about 4℃ lower
than incubator setting temperature.
▶ In case of low humidity incubation (70% ~ 85%): Fill the vermiculite( incubation sand)
which is to be purchased separately into the small incubating tray as shown in [Fig.- 1] ⓑ.
▶ In case of high humidity incubation (90% or more): In case the incubating environment is to be maintained 90%
or higher in humidity, fill the small incubating tray with 900cc of water as shown in [Fig.- 1 ] ⓐ and
put the vermiculite into it as shown in [Fig.- 1 ] ⓑ before mixing them.
That would facilitate the control of high humidity and remove the need of water filling.
1. Before starting incubation, fill water into the water tankⓒ,ⓓ of main body-2
as [ Fig.-2 ] for humidification.
Remove water from the tank before moving the incubator.
Otherwise the incubator can be out of order.
2. Humidification heater part [ Fig.-5] of the main body-1 should be soaked
inside of water tank when assembling with main body-2.
Be sure to check this, and cover the view window for connecting power cord.
▶ If you are going to incubate without water in the incubator,
you should turn off humidification function.
(Refer to How to turn off Humidification Function)
Do not apply force or shock to heater on the upper part of the body.
It may be the cause of failure.
Some foreign body can be stick to the heater part after hatching,
but there is no problem. (Refer to the "How to Clean)
3. After setting the incubation environment of the egg, install tray
inside of the incubator and operate it for 30 to 40 minutes
and put eggs into the tray.
4. Bury a low half of the eggs into the Vermiculite as[Fig.-1] and fix them.
(Check the conditions of the eggs once a week. Remove unfertilized eggs,
incompletely developed eggs, eggs covered with mold.)
5. Check the water for humidification everyday and fill it up as
shown in Fig - 4.
Stop supply of the water when styrofoam ball floats.
Do not reuse Vermiculite( incubation sand) after hatch.
If the incubation room is not properly controlled for high humidity (90~95%),
pour 75cc of water into four edges of the tray. ( See Fig. - 6)
And, pour 1000cc of water at the main body-2. [ Fig.- 3 ]
7. Operation Part
Temp. UP Button
Tray
Temp. DOWN Button
Daily Temp. Gap Function
Temp. Display
Water Cap
Heater Lamp
To facilitate water top-up
for the humidity control.
(Lighting when working)
Daily Temp. Gap Lamp
Lamp ON when Operation
What is Daily Temperature Gap Function?
▶
It is artificial promotion of nature condition of the highest temperature time zone.
By upraising the temperature at the specific time zone, it helps achieving the highest hatching success.
8. Easy Function Operation
Function
Temp. Setting
Humidity Setting
Daily Temperature Gap
Setting
Cels. / Fahr.
interchangable
Incubator Initialization
(Factory Setting)
How to turn off
Humidification Function
※ If you want to change setting value, keep pressing "SET" button and change the value.
75cc 75cc
75cc 75cc
[ Figure - 6 ]
[ Figure - 4 ]
Power Failure Alarm Function
Blick with power failure
(to remove, press SET button)
TEMP + TEMP + HUMI + HUMI +
TEMPERATURE HUMIDITY
CAL CAL
TEMP - TEMP - HUMI - HUMI -
HEATING HUMIDIFICATION
D.T.G. D.T.G. SET SET
TEMP.GAP WATER EMPTY
incubator
REFER TO "HOW TO START INCUBATION" FOR MORE INFORMATION.
How to Operate
SET SET
TEMP + TEMP +
TEMP - TEMP -
SET SET HUMI + HUMI +
HUMI - HUMI -
SET SET
D.T.G. D.T.G.
SET SET
TEMP - TEMP -
TEMP + TEMP +
SET SET
"OFF"
SET SET
HUMI - HUMI -
UNDER 40%
Ver E 3.2
ⓑ
Vermiculite( incubation sand) Vermiculite( incubation sand) Vermiculite( incubation sand)
ⓐ
Water Water
900cc
[ Figure - 1 ]
1000cc
③ ⓔ
[ Figure - 3 ]
ⓒ ⓐ
ⓑ ⓓ
[ Figure - 2 ]
Humidification
Heater Part
[ Figure - 5]
Humidity UP Button
Humidity DOWN Button
Setting Button
(Setting Value check)
Humidity Display
Humidification working lamp
(Lighting when working)
Water Supplement Lamp
(Blink with water shortage)
Explanation
Setting of required temp.
Setting of required humidity.
Daily Temp. Gap ON /
Daily Temp. Gap OFF
(Three hours operation per day)
/ +1.5℃
℃↔℉
How to change Cels. or Fahr.
Initialization
In case of low humidity
incubation
