Lamp Replacement

The lamp should be replaced when it reaches the end of its life (typically 2000 hours),
or sooner if a noticeable degradation in brightness occurs.
1. Turn off the projector and unplug the power
cord. Allow the projector to cool down for
approximately 45 minutes prior to removing
the lamp assembly for replacement.
2. Remove the two screws from the lamp cover.
3. Remove the lamp cover.
4. Remove the two screws from the lamp module.
5. Pull the lamp module straight out to remove it.
6. Insert the new lamp module securely and replace
the two screws.
7. Replace the lamp cover at the right side first as
shown and secure it with the two screws.
8. Turn on the power and go into the Setup/Reset
Lamp Timer menu to reset the lamp timer. Refer
to "Set Up" in the previous section, On-Screen
Display Menus.
