On-Screen Display Menus
Picture Quality
Adjustments
Brightness ➤
Contrast ➤
Sharpness ➤
Filter ➤
Runco CL-610
> Video
S-Video
Component1
Component2
RGB-HD
HDMI
------------------------
Aspect Ratio
Installation
Option
Setup
ISF Calibration
To access the picture quality adjustments, press Menu, highlight the active source and
press Enter or ►. The picture quality sub-menu then appears (see above).
To adjust a setting, highlight it with the ▲ or ▼ button and press Enter to activate a
scroll bar for that setting. Use the ◄ or ► keys to change the setting. When finished,
press Exit.
Select Brightness to adjust the black level of the projected image (0 = minimum;
60 = maximum).
Select Contrast to adjust the white level of the projected image (0 = minimum;
32 = maximum).
Select Color to adjust the color level (saturation) of the projected image (0 = minimum;
Color ➤
64 = maximum).
Select Tint to adjust the hue of the projected image (0 = minimum; 30 = maximum).
Tint ➤
Select Sharpness to adjust the sharpness of the projected image (-14 = minimum;
+20 = maximum). This setting has no effect if the Sharpness Filter is set to 0 (refer to
the next paragraph).
The Filter setting controls the behavior of the Sharpness control. The available
settings depend on the vertical resolution of the input signal, as follows:
• With a 480i signal, you can apply the sharpness control to either the input signal
(1), the output signal (2), both (3) or neither (0).
With a 480p or higher-resolution signal, the sharpness control is applied only
•
to the output signal and only when you set the Sharpness filter to "on" (1).
Adjustment
Brightness
Contrast
Color
Tint
Sharpness
Filter
Color Temperature
ICC Selection
Store Image Settings
Restore Image Settings
32
