Smartcard

STMicroelectronics smartcard interface chip ST8024 is used on the STM3210E-EVAL board
for asynchronous 3V and 5V smartcards. It performs all supply protection and control
functions based on the connections with STM32F103Z listed in
The Smartcard_CMDVCC and Smartcard_OFF are multiplexed with motor control.
They can be enabled by setting the jumpers JP15 and JP16. Refer to
control on page 10
Table 7.
Signals of ST8024
5V/3V
I/OUC
XTAL1
OFF
RSTIN
CMDVCC
Table 8.
Jumper
JP15
JP16
2.11

MicroSD card

The 128 Mbyte MicroSD card connected to SDIO of STM32F103Z is available on the board.
MicroSD card detection is managed by standard IO port PF11.
The MicroSD card_D3 is multiplexed with IrDA. It can be enabled by setting the jumper
JP22, as explained in
The MicroSD card_D0 and MicroSD card CMD are multiplexed with the motor control
connector. They can be enabled by setting the jumpers JP17 and JP20.
Table 9.
Jumper
JP17
JP20
for details.
Connection between ST8024 and STM32F103Z
Smartcard power supply selection pin
MCU data I/O line
Crystal or external clock input
Detect presence of a card, interrupt to MCU,
share same pin with motor controller
Card reset input from MCU
Start activation sequence input (active low),
share same pin with I
Smartcard related jumpers
The CMDVCC is connected to PC6 when JP15 is closed. It should be kept on
open, or the SD card needs to be removed from the MicroSD card connector
when PC6 is used by I
The OFF is connected to PC7 when JP16 is closed. It has to be kept on open
when PC7 is used by the motor control connector. Default setting: not fitted
Section 2.14: IrDA on page
MicroSD card related jumpers
JP17 is used to enable MicroSD card data line D0. MicroSD card D0 is enabled
when JP17 is fitted. The JP17 should be kept on open when motor control
connector CN1 is used. Default setting: fitted
JP20 is used by the motor control connector, refer to
should be kept on open for MicroSD card operation. JTAG debugging is
disabled when JP20 is fitted.
Hardware layout and configuration
Description
2
S DAC and motor control
Description
2
S or motor control connector. Default setting: not fitted
12.
Description
Table 7.
Section 2.9: Motor
Connect to
STM32F10X
PB0
PB10
PB12
PC7
PB11
PC6
Table 6 for details. JP20
