Pin Out – I/O Connector - Measurement Computing PCI-PDISO16 User Manual

User's Guide
The pinout for connector P2 is defined in
Pin out – I/O
connector
Table 2-2.
Connector P2 pin out
Table 2-3.
Connector P3 pin out
Caution! High voltages are present on the PCI-PDISO16 board when you connect high voltage inputs or
outputs to the board's connector.
when signals are connected to the board through the connector. Do not remove the
protective plates on the PCI-PDISO16 board.
Table 2-2 . The pinout for connector P3 is defined in Ta
Signal Name Pin
NC 50 • •
NC 48 • •
NC 46 • •
NC 44 • •
NC 42 • •
RELAY 6 (NC) 40 • •
RELAY 7 (NC) 38 • •
RELAY 0 (C) 36 • •
RELAY 1 (NO) 34 • •
RELAY 1 (NC) 32 • •
RELAY 2 (C) 30 • •
RELAY 3 (NO) 28 • •
RELAY 3 (NC) 26 • •
RELAY 4 (C) 24 • •
RELAY 5 (NO) 22 • •
RELAY 6 (NO) 20 • •
RELAY 7 (NO) 18 • •
INPUT 0 16 • •
INPUT 1 14 • •
INPUT 2 12 • •
INPUT 3 10 • •
INPUT 4 8 • •
INPUT 5 6 • •
INPUT 6 4 • •
• •
INPUT 7 2
↓
PCI slot
Signal Name Pin
NC 50 • •
• •
NC 48
NC 46 • •
NC 44 • •
NC 42 • •
• •
RELAY 6 (NC) 40
RELAY 7 (NC) 38 • •
• •
RELAY 0 (C) 36
RELAY 1 (NO) 34 • •
RELAY 1 (NC) 32 • •
RELAY 2 (C) 30 • •
RELAY 3 (NO) 28 • •
RELAY 3 (NC) 26 • •
RELAY 4 (C) 24 • •
RELAY 5 (NO) 22 • •
RELAY 6 (NO) 20 • •
RELAY 7 (NO) 18 • •
INPUT 0 16 • •
INPUT 1 14 • •
INPUT 2 12 • •
INPUT 3 10 • •
INPUT 4 8 • •
INPUT 5 6 • •
INPUT 6 4 • •
INPUT 7 2 • •
↓
PCI slot
Use extreme caution! Never handle the PCI-PDISO16 board
2-4
Installing the PCI-PDISO16
Pin Signal Name
49 NC
47 NC
45 NC
43 NC
41 NC
39 RELAY 5 (NC)
37 RELAY 0 (NO)
35 RELAY 0 (NC)
33 RELAY 1 (C)
31 RELAY 2 (NO)
29 RELAY 2 (NC)
27 RELAY 3 (C)
25 RELAY 4 (NO)
23 RELAY 4 (NC)
21 RELAY 5 (C)
19 RELAY 6 (C)
17 RELAY 7 (C)
15 INPUT 0
13 INPUT 1
11 INPUT 2
9 INPUT 3
7 INPUT 4
5 INPUT 5
3 INPUT 6
1 INPUT 7
Pin Signal Name
49 NC
47 NC
45 NC
43 NC
41 NC
39 RELAY 5 (NC)
37 RELAY 0 (NO)
35 RELAY 0 (NC)
33 RELAY 1 (C)
31 RELAY 2 (NO)
29 RELAY 2 (NC)
27 RELAY 3 (C)
25 RELAY 4 (NO)
23 RELAY 4 (NC)
21 RELAY 5 (C)
19 RELAY 6 (C)
17 RELAY 7 (C)
15 INPUT 0
13 INPUT 1
11 INPUT 2
9 INPUT 3
7 INPUT 4
5 INPUT 5
3 INPUT 6
1 INPUT 7
ble 2-3 .
