UM0488
Jumper
JP14
2.16

Development and debug support

The two debug connectors available on the STM3210E-EVAL evaluation board are:
•
CN9: standard 20-pin JTAG interface connector, compliant with ARM7/9 debug tools.
•
CN7: SAMTEC 20-pin connector FTSH-110-01-L-DV for both SWD and Trace,
compliant with ARM CoreSight debug tools.
2.17

Display and input devices

The 240x320 TFT color LCD connected to bank1 NOR/PSRAM4 of FSMC interface of the
STM32F103ZGT6 and four general purpose color LEDs (LD 1,2,3,4) are available as
display devices. A 4-direction joystick with selection key, general purpose button (B4),
wakeup button (B2) and tamper detection button (B3) are available as input devices.
The jumper JP4 should be kept open to enable the wakeup button B2 which shares the
same I/O with USART2 and motor control connector.
The STM3210E-EVAL evaluation board also supports a second optional 122x32 graphic
LCD that can be mounted on the U18 connector. By default, the graphic LCD is not present.
Pin on
CN16
1
2
3
4
5
6
7
8
9

Table 11. USB related jumpers

The USB 1.5K pull-up resistor is always connected to USB+ line when
JP14 is set as shown.
The USB 1.5K pull-up resistor can be disconnected by software from
USB+ line when JP14 is set as shown. In this case, the USB
connect/disconnect feature is managed by standard IO port PB14
(default setting).
TFT LCD CN16 (default)
Description Pin connection
CS of Bank3 of
CS
FSMC
RS FSMC_A0
WR/SCL FSMC_NWE
RD FSMC_NOE
RESET RESET#
PD1 FSMC_D0
PD2 FSMC_D1
PD3 FSMC_D2
PD4 FSMC_D3
DocID14220 Rev 6
Hardware layout and configuration
Description

Table 12. LCD modules

Pin on
U18
1
2
3
4
5
6
7
8
Graphic LCD U18 (optional)
Description Pin connection
Vss GND
Vcc 3.3V
VO -
CLK PA5
SID PA7
CS PF10
A +5V
K GND
1 2 3
1 2 3
15/50
