STM3210E-EVAL I/O assignment
Pin #
68 PE15
69 PB10
70 PB11
71 VSS_1
72 VDD_1
73 PB12
74 PB13
75 PB14
76 PB15
77 PD8
78 PD9
79 PD10
80 PD11
81 PD12
82 PD13
83 VSS_8
84 VDD_8
85 PD14
86 PD15
87 PG2
88 PG3
89 PG4
90 PG5
91 PG6
92 PG7
93 PG8
94 VSS_9
95 VDD_9
96 PC6
97 PC7
98 PC8
99 PC9
100 PA8
101 PA9
102 PA10
46/50
Table 29. STM3210E-EVAL I/O assignment (continued)
Pin name
FSMCD12
Smart_IO
Smart Reset
GND
+3V3
Smart_CK / MC_pin21 (NTC) / Audio I2S_CMD
Audio I2S_CK
USB Disconnect
Audio I2S_DIN
FSMCD13
FSMCD14
FSMCD15
FSMCA16
FSMCA17
FSMCA18
GND
+3V3
FSMCD0
FSMCD1
FSMCA12
FSMCA13
FSMCA14
FSMCA15
FSMC_INT2
JOY_Select
User Button B4
GND
+3V3
MC_TIM5_CH1 pin 3 (UH) / Smart_ CMD / VCC/I2S_MCK
MC_TIM5_CH2 pin 7(VH) / Smartcard_OFF
MC_TIM5_CH3 pin 11 (WH) / MicroSD Card D0
MicroSD Card D1
MCO / LCD backlight /QST pin11
USART1 TX
USART1 RX
