ILD1700 Tool
5.4.4.6 Clear buffer
This button can be used to empty all data buffers and switch into live mode.
5.4.5 F1/F2 Upper limit
This LED displays the state of the output for the upper limit. A red LED
indicates the upper limit is violated and the corresponding limit output is set
to high. A green LED shows the limit output is set to low.
5.4.6 F2/F1 Lower limit
The same as the upper limit except that it indicates when the lower limit is
violated.
___________________________________________________________________________
Micro-Epsilon Page 16
