Chapter 3: BIOS Setup

CPU Configuration

This section is used to configure the CPU.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Core(TM) i5-4670S CPU @ 3.10GHz
CPU Signature
306c3
Processor Family
6
Microcode Patch
9
FSB Speed
100 MHz
Max CPU Speed
3100 MHz
Min CPU Speed
800 MHz
CPU Speed
3400 MHz
Processor Cores
4
Intel HT Technology
Not Supported
Intel VT-x Technology
Supported
Intel SMX Technology
Supported
64-bit
Supported
EIST Technology
Supported
CPU C3 state
Supported
CPU C6 state
Supported
CPU C7 state Supported
L1 Data Cache
32 kB x 4
L1 Code Cache
32 kB x 4
L2 Cache
256 kB x 4
L3 Cache
6144 kB
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Hyper-threading
This field is used to enable or disable hyper-threading.
Active Processors Cores
Select the number of cores to enable in each processor package.
Limit CPUID Maximum
The CPUID instruction of some newer CPUs will return a value greater
than 3. The default is Disabled because this problem does not exist in the
Windows series operating systems. If you are using an operating system
other than Windows, this problem may occur. To avoid this problem, enable
this field to limit the return value to 3 or lesser than 3.
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.
▲
Number of cores to enable in
each processor package.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
33
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
100 MHz
FSB Speed
3100 MHz
Max CPU Speed
800 MHz
Min CPU Speed
3400 MHz
CPU Speed
4
Processor Cores
Not Supported
Intel HT Technology
Intel VT-x Technology Supported
Intel SMX Technology Supported
Supported
64-bit
Supported
EIST Technology
Supported
CPU C3 state
Supported
CPU C6 state
Supported
CPU C7 state
32 kB x 4
L1 Data Cache
L1 Code Cache 32 kB x 4
L2 Cache 256 kB x 4
L3 Cache 6144 kB
[Enabled]
Hyper-threading
[All]
Active Processor Cores
[Disabled]
Limit CPUID Maximum
[Enabled]
Intel Virtualization Technology
[Enabled]
EIST
Turbo Mode [Enabled]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Intel Virtualization Technology
®
When this field is set to Enabled, the VMM can utilize the additional
hardware capabilities provided by Vanderpool Technology.
EIST
Enables or disables Intel SpeedStep.
®
Turbo Mode
Enables or disables turbo mode.
▲
Turbo Mode.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
