Chapter 2: Jumpers and Connectors
FP Audio Connector
Connector type: 2x5 10-pin header
Connector location: JP1
2
10
1
9
Pin
Definition
1
MIC2_L
3
MIC2_R
5
LINE2_R
7
GND
9
LINE2_L
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
FP_AUD_DETECT
6
MIC2_JD
10
LINE2_JD
FP Control Connector
Connector type: 2x5 10-pin header
Connector location: JFP1
2
1
9
Pin
Definition
1
SATA_LED_P
3
SATA_LED_N
5
GND
7
RST_BTN_N
9
NC
16
Pin
Definition
2
PWR_LED_P
4
GND
6
PWRBT_N
8
GND
NEX 885 User Manual
