Chapter 2: Jumpers and Connectors

PEG x16 Slot

Connector location: JP3
A1 A11 A12
B1 B11 B12
Pin Definition
A1 NC
A2 VCC12
A3 VCC12
A4 GND
A5 NC
A6 NC
A7 NC
A8 NC
A9 VCC3
A10 VCC3
A11 PERST#
A12 GND
A13 REFCLK_P
A14 REFCLK_N
A15 GND
A16 RXP0
A17 RXN0
A18 GND
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.
A82
B82
Pin Definition
B1 VCC12
B2 VCC12
B3 VCC12
B4 GND
B5 SMB_CLK
B6 SMB_DATA
B7 GND
B8 VCC3
B9 TRST#
B10 3VSB
B11 WAKE#
B12 RSV
B13 GND
B14 TXP0
B15 TXN0
B16 GND
B17 PRSNT2#
B18 GND
Pin Definition
A19 RSV
A20 GND
A21 RXP1
A22 RXN1
A23 GND
A24 GND
A25 RXP2
A26 RXN2
A27 GND
A28 GND
A29 RXP3
A30 RXN3
A31 GND
A32 RSV
A33 RSV
A34 GND
A35 RXP4
A36 RXN4
22
Pin Definition
B19 TXP1
B20 TXN1
B21 GND
B22 GND
B23 TXP2
B24 TXN2
B25 GND
B26 GND
B27 TXP3
B28 TXN3
B29 GND
B30 RSV
B31 PRSNT2#
B32 GND
B33 TXP4
B34 TXN4
B35 GND
B36 GND
