Chapter 3: BIOS Setup
Advanced
The Advanced menu allows you to configure your system for basic operation.
Some entries are defaults required by the system board, while others, if
enabled, will improve the performance of your system or let you set some
features according to your preference.
Setting incorrect field values may cause the system to
malfunction.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main
Advanced
Chipset
Security
CPU Configuration
AMT Configuration
Trusted Computing
ACPI Settings
NCT6791D Super IO Configuration
NCT6791D HW Monitor
F81216 Super IO Configuration
USB Configuration
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Boot
Save & Exit
CPU Configuration Parameters
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CPU Configuration
This section is used to configure the CPU settings.
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced
CPU Configuration
Type
ID
Speed
L1 Data Cache
L1 Instruction Cache
L2 Cache
L3 Cache
L4 Cache
VMX
SMX/TXT
Intel (VMX) Virtualization
Technology
Active Processor Cores
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
Intel
(VMX) Virtualization Technology
®
When this field is set to Enabled, the VMM can utilize the additional
hardware capabilities provided by Vanderpool Technology.
Active Processor Cores
Select the number of cores to enable in each processor package.
23
When this field is set to Enabled,
the VMM can utilize the
additional hardware capabilities
Intel(R) Core(TM)
provided by Vanderpool
i5-6500 CPU @ 3.20GHz
Technology.
0x506E3
3200 MHz
32 KB x 4
32 KB x 4
256 KB x 4
6 MB
N/A
Supported
Supported
→←: Select Screen
↑↓: Select Item
[Enabled]
Enter: Select
+/-: Change Opt.
F1: General Help
[All]
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NEX 912 User Manual
