Chapter 3: UEFI Setup Utility

3.3.1 CPU Configuration

Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced H/M Monitor
Intel ® Core(TM) i5-3550S CPU @ 3.00GHz
Max CPU Speed 3000 MHz
Min CPU Speed 1600 MHz
Processor Cores 4
Intel HT Technology Not Supported
IntelVT-X Technology Supported
Intel SMX Technology Supported
64-bit Supported
CPU Ratio [Auto]
Intel SpeedStep Technology [Enabled]
Intel Turbo Boost Technology [Enabled]
Long Duration Power Limit Auto
Long Duration Maintained [Auto]
Short Duration Power Limit Auto
Primary Plane Current Limit Auto
Secondary Plane Current Limit Auto
Active Processor Cores [All
Enhanced Halt State(C1E) [Enabled]
CPU C3 State Support [Enabled]
CPU C6 State Support [Enabled]
Package C State Support [Auto]
CPU Thermal Throtting [Enabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
CPU Ratio
Use this item to change the ratio value of this motherboard.
Intel SpeedStep Technology
Intel SpeedStep technology is Intel's new power saving technology.
Processors can switch between multiple frequencies and voltage points to
enable power saving. The default value is [Enabled]. Configuration options:
[Enabled] and [Disabled]. If you install Windows
to enable this function, please set this item to [Enabled]. This item will be
hidden if the current CPU does not support Intel SpeedStep technology.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Security Save & Exit
Adjust CPU Turbo Ratio, CPU
Core Frequency will be Ratio *
BCLK
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
VistaTM / 7 / 8 and want
®
Please note that enabling this function may reduce CPU voltage
and lead to system stability or compatibility issues with some
power supplies. Please set this item to [Disabled] if above issues
occur.
Intel Turbo Boost Technology
Use this item to enable or disable Intel Turbo Boost Mode Technology.Turbo
Boost Mode allows processor cores to run faster than marked frequency in
specific conditions. The default value is [Enabled].
Long Duration Power Limit
Use this item to configure long duration power limit in watts. The default
value is [Auto].
Long Duration Maintained
Use this item to configure time window which the long duration power is
maintained. The default value is [Auto].
Short Duration Power Limit
Use this item to configure short duration power limit in watts. The default
value is [Auto].
Primary Plane Current Limit
Use this item to configure the maximum instantaneous current allowed for
the primary plane. The default value is [Auto].
23
