Celltron ULTRA
Main Menu (menu icon)
BATTERY SETUP (menu icon)
NEW (TEST) (icon) (Continued from POSTS PER JAR)
STRING INFO (scrolling parameters list)
BATTERY MANAGER (scrolling)
Press ENTER to select a jar manufacturers and model, and
computer a reference value.
SELECT MANUFACTURER
Press ENTER to display jar manufacturers and models.
SELECT MFGR (scrolling/alphanumeric)
Select from an alphabetical list of approximately 16
manufacturers, or select USER VENDOR (three
available) to create a name for an unlisted manu-
facturer.
SELECT MODEL (scrolling/alphanumeric)
Select from an alphabetical list of over 200
models, or select USER DEFINED (approx.
64 available) to create a name for an unlisted
model.
REFERENCE DEVELOPER
Press ENTER to have the analyzer compute a reference
value.
REF DEVELOPER (scrolling/numeric)
Select a percentage of jars on the string on which to
base a reference (from 0 to 100%).
REFERENCE (scrolling/alphanumeric)
The default is dashes (
Press ENTER to change the value. This setting uses the
manufacturer's reference value for the model of jar selected in
BATTERY MANAGER. If you use REFERENCE DEVELOPER,
the setting displays asterisks ( ***** ) and cannot be changed.
(To VOLT & CONDUCTANCE)
15
Chapter 2: Description
).
– – – – – –
