Chapter 5: Selecting test parameters

Adding jar model information to the database

To add new jar models and conductance reference values to the database, use BATTERY MANAGER
in the Main Menu. The BATTERY MANAGER available in BATTERY SETUP allows you to change
a reference value only for a particular data fi le. It does not save the change as a selection for new
test setups. You can also edit a model name or add a new model using BATTERY MANAGER in the
Main Menu.

Changing a reference value

1. Press the ARROW keys to highlight the BATTERY MANAGER in the Main Menu, and press
ENTER .
2. Press the ARROW keys to select a manufacturer, and press ENTER .
3. To change a reference value for a model in the database, press the ARROW keys to select
the model name, and press ENTER .
4. In the EDIT MFGR screen, press the DOWN ARROW to select REFERENCE, and press
ENTER .
NOTE: If you change the model name and save it, the new name overwrites the original
model name in the database.
5. Press the ARROW keys (or use the numeric keypad) to select a new reference value, and
press ENTER .
6. To save, press the DOWN ARROW to select SAVE AND CONTINUE, and press ENTER .

Adding a jar model

1. Press the ARROW keys to highlight the BATTERY MANAGER in the Main Menu, and press
ENTER .
2. Press the ARROW keys to select a manufacturer, and press ENTER .
3. Press the ARROW keys to select
ENTER .
4. In the MODEL ID screen, your USER DEFINED selection is highlighted. Press ENTER to
change the name.
5. The cursor blinks to the right of the last space or character in the name. Display the charac-
ter, symbol, or number you want by rapidly pressing its key as many times as needed. If you
pause, the cursor moves to the right. To backspace one character, press the BACK key. To
enter a space between characters, press the
6. In the MODEL ID screen, press the DOWN ARROW to select REFERENCE, and press
ENTER .
7. Press the ARROW keys (or use the numeric keypad) to select a new reference value.
8. To save, press the DOWN ARROW to select SAVE AND CONTINUE and press ENTER .
d USER DEFINED nam
one of the numbere
key twice. Press ENTER when fi nished.
34
• •
Celltron ULTRA
, and press
es
