Chapter 2: Description Celltron ULTRA

Selection screens

When you turn on the analyzer it will default to the last menu screen displayed. To move back to the
Main Menu, press the BACK key as each submenu appears.
The Main Menu has six menus: BATTERY SETUP, TEST, REPORTS, UTILITIES SETUP, DMM
(Digital Multimeter), and BATTERY MANAGER. The menus have several submenus or options to
help you set up the analyzer for testing, automate portions of the test process, and manage test data.
The settings contain factory defaults that you can overwrite using the keypad. For more information,
refer to the sections in the manual on selecting test parameters and utilities. The keys you use to
enter data depend on the type of selections displayed. There are four types:

Menu icons

A menu icon is a graphical representation of a function you can select and use, such as the BATTERY
SETUP icon in the Main Menu.
To select an icon, use the ARROW ( or ) keys to highlight it, and press the ENTER key. To return
to the previous menu, press the BACK key.

Scrolling lists

Scrolling lists contain items that extend above and below the screen or the selection box that contains
them. To indicate that there are more items, the symbols appear to the right of the fi rst item on the
list. To select from a list, use the ARROW keys to scroll to the item and press ENTER .

Check boxes

Lists that fi t the screen have check boxes before each item. Use the ARROW keys to place the check
in the box next to your selection, or use the numeric keys to enter the item number. Press ENTER
to select.

Alphanumeric selections

Some selections require you to use the alphanumeric keypad. These "user-defi ned" selections
are indicated by a blinking horizontal line (cursor) to the right of the last character. Display the
character, symbol, or number you want by rapidly pressing its key as many times as needed.
If you pause, the cursor moves to the right. To backspace one character, press the BACK key.
To enter a space between characters, press the key twice. Press ENTER when fi nished.

Menu structure

This section describes the menu structure using a tree diagram to help you navigate through the
screens. Selectable items are capitalized or in bold, and screen titles are italic.
You can fi nd more detailed information on how to select options and test parameters in Chapters 4
and 5.
