C 6: C
74
HAPTER ONFIGURING THE
Viewing Network
Statistics
Table 17 Statistics Available
Menu Option
Display General Statistics
Display Physical Layer
Statistics
Reset Physical-Layer
Statistics
Display ATM-Layer Port
Statistics
Reset ATM-Layer Port
Statistics
Display ATM-Layer VPI/VCI
Statistics
Reset ATM-Layer VCI/VPI
Statistics
AAL5 Control Statistics
Reset AAL5-Layer Control
Statistics
Display Signaling Protocol
Statistics
C B 7000 F
ORE UILDER
information to the other ports (slave ports). For more information, see
"Set and Save Clock Synchronization Mode" on page 120 in the
Management Guide
At any time after configuring the CoreBuilder 7000 family ATM switch,
you can view the available statistics to see how the network is
functioning. For example, you may want to display the general statistics
for an overview of the network, or the signalling statistics for protocol
information on specific ports. Table 17 lists the types of statistics
available. To view a specific statistic, enter the menu path shown in the
table. For more information, see the CoreBuilder 7000 Family ATM Switch
Management Guide .
Path
(4) STS: Statistics
(1) GEN: General switch stats
(4) STS: Statistics
(2) PHY: Physical layer
(4) STS: Statistics
(8) PHR: Phy layer-reset counters
(4) STS: Statistics
(3) ATM: ATM layer
(1) PRT: Stats per port
(4) STS: Statistics
(9) ATR: ATM layer-reset counters
(1) PRT: Reset counters per port
(4) STS: Statistics
(3) ATM: ATM layer
(2) VPC: Stats per VPI/VCI
(4) STS: Statistics
(9) ATR: ATM layer-reset counters
(2) VCC: Reset counters per
VPI/VCI
(4) STS: Statistics
(5) CTL: Control frames
(1) GET: Get Control frames
(4) STS: Statistics
(5) CTL: Control frames
(2) RES: Reset Control frames
(4) STS: Statistics
(6) SIG: Signaling
ATM S
AMILY WITCH
Description
Displays statistical totals for the switch.
Displays the physical layer statistics for a specified
port.
Resets physical statistics counters.
Displays the ATM layer statistics for a specified
port. Provides information on the capacity of traffic
within ports.
Resets the ATM-layer counters for a specified port.
Displays the ATM layer statistics for a VPI/VCI of a
specified port.
Resets counters for an individual and every VPI/VCI
for a specified port.
Displays the control frames (AAL5 layer) statistics,
including protocol information, for a specified port.
Resets AAL5-layer control statistics for a specified
port.
Displays the signaling protocol statistics for a
specified port.
