4-Port Interface
Module
ATM Interface
Daughter Cards
This section contains the following topics:

ATM Interface Daughter Cards

Installing the ATM Interface Daughter Cards
Installing a 4-Port Interface Module
Replacing a 4-Port Interface Module
Each of the four ATM interface receptacles of the 4-Port ATM Interface
module can be configured to support the following types of ATM
daughter cards:
OC-3 multi-mode (MM) fiber link, single-mode (SM) fiber link
DS-3 coaxial cable
E-3 ATM 34.368 Mbits/sec WAN interface
Figure 5 shows the OC-3 daughter card.
Figure 5 OC-3 Daughter Card
Figure 6 shows the DS-3 daughter card.

4-Port Interface Module

41
