Setting Up Switch Module Hardware Redundancy; Setting Up Hardware Redundancy And Lane Redundancy - 3Com CoreBuilder 7000 Installation & Start?Up Manual

Setting up Switch
Module Hardware
Redundancy
Slot id Slot status
-------
1 Occupied
2 Occupied
Setting up Hardware
Redundancy and
LANE Redundancy
Use the following procedure to set up the switch module hardware
redundancy.
1 Designate and mark the main and redundant switch modules.
2 Insert the switch module you marked as "redundant" in slot 2. Do not
insert the switch module you marked as "main" yet.
3 Turn on the CoreBuilder 7000 family ATM switch.
The switch module in slot 2 becomes active.
4 Run the Integrated Fast Setup procedure (see "Integrated Fast Setup" on
page 56.) using the LMA command
(9) FST
5 Insert the main switch module in slot 1.
6 Reboot the CoreBuilder 7000 family ATM switch using the LMA menu
sequence:
(1) SYS / (7) RBO
The switch module in slot 1 becomes active.
7 Verify main and redundant switch module status using the LMA
command:
(1) SYS / (4) SWM
You should see the following display.
Switch type
----------- ----------------
16x16 ATM switch
16x16 ATM switch
8 Run the Integrated Fast Setup procedure using the LMA command
to verify the configuration in the main switch module.
(9) FST
The switch is now operational.
This section presents a procedure for setting up both switch module
hardware redundancy and LANE redundancy in the same session. Both
the LMA and the Transcend Enterprise Manager are used.
.
Switch mode
------------
Active
Redundant
Switch Module 35
Memory size
-----------
8M
8M
