Mounting The Corebuilder 7000 Family Atm Switch - 3Com CoreBuilder 7000 Installation & Start?Up Manual

C 3: I
28
HAPTER NSTALLING A
Mounting the
CoreBuilder 7000
Family ATM Switch
C B 7000 F
ORE UILDER AMILY
Once the distribution rack is ready, you can mount the CoreBuilder 7000
family ATM switch into the rack.
To mount the CoreBuilder 7000 family ATM switch into the distribution
rack:
1 Carefully lift the CoreBuilder 7000 family ATM switch into place, aligning
the mounting brackets to the holes you have designated for mounting.
A fully-configured CoreBuilder 7000 family ATM switch weighs 43
pounds as shipped. To avoid personal injury, do not lift the unit without
assistance.
2 While holding the CoreBuilder 7000 family ATM switch in place, firmly
insert the mounting screws (10/32 x 1/2 Phillips) into the mounting holes
on both sides of the rack.
The unit is now installed in the distribution rack.
To insert the power supply, switching modules, and interface cards,
configure optical ports for the interface modules and connect network
cabling and power to the unit see Chapter 4.
ATM S
WITCH
