4. The display should change to the "Ch A VOLT-
AGE CONFIG" screen. The configured items
for voltage are Input Ratio and Phase Offset.
5. Press or to select desired field and ENT to
select value to change.
Input Ratio
6. Enter the ratio values from the numeric keypad
and press ENT to move to the next field. Note
that all ratios are referenced to 1. For the ex-
ample screen above, the Input Ratio is actually
1:1.
Phase Offset
7. Enter the Phase Offset value from the numeric
keypad and press ENT to move to the next field.
In this example, the phase offset is 0.0 .
8. When finished configuring the channel, highlight
STOre And Exit
any new values and return to the Channel Con-
figuration menu. Press ESC to leave the Channel
Configuration menu and return to the measure-
ment mode.
and press ENT to install
