Arbiter Systems 928A User Manual page 8

Basic Functions and Keys . . . . . . . . . . . 13
MIN/MAX - Range . . . . . . . . . . . 13
LCD - Display Control . . . . . . . . . . 13
Function Keys, f1 - f6 . . . . . . . . . . 14
Splash Screen . . . . . . . . . . . . . . . 14
Up and Down Arrows . . . . . . . . . . 14
MENU - Configuration and Settings . . 15
Menus in Context . . . . . . . . . . . . . 18
ENT - Enter or Move . . . . . . . . . . 18
ESC - Escape, Go Back . . . . . . . . . 19
STO - Store Value or Reading . . . . . 19
TIME - View or Set Time . . . . . . . . 20
DATE - View or Set Date . . . . . . . . 21
Using the Input Channels . . . . . . . . . . . 22
Configuring Channels A and B . . . . . 23
Using the MN352 Current Probe . . . . 29
CT Characterization Files . . . . . . . . 30
Operation
Introduction . . . . . . . . . . . . . . . . . . . 31
Making Measurements . . . . . . . . . . . . . 32
VI - Voltage and Current . . . . . . . . 32
F - Phase and Frequency . . . . . . . . 34
PWR - Active and Reactive Power . . . 36
PF - Power Factor & Apparent Power . 38
Wh - Watt-hour . . . . . . . . . . . . . 40
WAV - Waveform . . . . . . . . . . . . . 42
HRM - Numerical Harmonics . . . . . . 44
Graphical Harmonics . . . . . . . . . . . 45
Flicker Information . . . . . . . . . . . . 46
FLK - Instantaneous Flicker . . . . . . 47
Pst - Short-Term Flicker . . . . . . . . . 47
PQ - Power Quality, Sags and Swells . . 48
TRIG - Working with Triggers . . . . . 54
Configuring Triggers . . . . . . . . . . . 55
viii
31
