Details

Input Sections

Two identical input channels (A and B) allow users
to connect to voltage sources (0 to 660 Vrms) and to
current sources (0 to 1.2 Arms or 0 to 1.2 Vrms), de-
signed to work with a CT up to approximately 1000
A. To allow accurate measurements at low current lev-
els ( 10 A) there will be a 100 'booster' amplifier
available to extend the input current range downwards
to about 10 – 100 mA (with a 1000:1 external CT) for
full accuracy and lower with somewhat reduced per-
formance. Current Inputs are connected to the upper
connectors and allow for a voltage output or current
output CT. The current input section has a 1000:1 CT
giving an output current of 0 to 1 mA, which is then
converted to a voltage. The voltage input section uses
medium-power, low TC resistors that accept up to 660
Vrms with a 1 Vrms signal to the ADC.
The current input sections are able to accept either
1.2 Arms or 1.2 Vrms max input. This will accommo-
date either current or voltage output probes.

MUX and ADC

The ADC is a 24-bit Texas Instruments ADS1251
sigma delta converter running at 10240 samples-per-
second. There are two multiplexers being used: a
74HC4053 and a 74HC4052. The '4053' is being used
to switch between the voltage and current channel in-
puts, and the '4052' switches the source for current
channels: either a current CT (maximum input 1.2
Arms), voltage CT (maximum input of 1.2 Vrms) or
gain of 20.
