Configuring Channels A and B
Configure Channels A and B, for both current and
voltage through this menu. Four possibilities exist:
Ch-A V Channel A measuring a voltage
Ch-A I Channel A measuring a current
Ch-B V Channel B measuring a voltage
Ch-B I Channel B measuring a current
You can completely configure all these possibilities
at one time from the Channel Configuration menu.
Voltage, Ch-A V
1. Press VI to open the measurement mode.
2. Press 2nd MENU to open the configuration
screen for Channels A and B.
3. Press or to highlight the channel and ENT to
open the specific Channel configuration screen.
In this example, Ch-A V sets the voltage mea-
surement parameters for Channel A.
23
