Danfoss VLT HVAC Drive FC 102 Instruction Manual page 47

Electrical Installation
2
1
8, 9
7
6
1) External temperature monitoring
2) AUX relay
01 02 03
04 05 06
3) NAMUR
4) AUX fan
100 101 102 103
L1 L2 L1 L2
5) Brake
-R +R
81 82
Figure 4.8 Inverter Cabinet, Enclosure Types F2 and F4
MG11F522
Instruction Manual
3
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97
6)
7)
8)
9)
Danfoss A/S © 08/2014 All rights reserved.
4
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
W/T3 98 U/T1 96 V/T2 97 W/T3 98
Motor
U V W
96 97 98
T1 T2 T3
NAMUR fuse (see Table 4.23 for part numbers)
Fan fuses (see Table 4.19 for part numbers)
SMPS fuses (see Table 4.18 for part numbers)
5
45
4 4
