Mechanical Installation

3.4.11 Installation of Input Plate Options

This section describes the field installation of input option kits available for adjustable frequency drives in all E enclosures.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input
3 3
plate.
NOTICE!
Two different types of RFI filters are available, depending on the input plate combination and whether the RFI filters are
interchangeable. Field installable kits are, in certain cases, the same for all voltages.
E1
Table 3.10 Fuses, Enclosure Size E1 380–500 V
E1
Table 3.11 Fuses, Enclosure Size E1 525–690 V
NOTICE!
For further information, see the Instruction Installation of Field Installable Kits for VLT Drives.
36
380–480 V Fuses
380–500 V
FC 102/FC 202: 315 kW 176F0253
(430 hp)
FC 302: 250 kW (350
hp)
FC 102/FC 202: 355–450 176F0254
kW (475–600 hp)
FC 302: 315–400 kW
(425–550 hp)
525–690 V Fuses
FC 102/FC 202: 450– 176F0253
500 kW (600–650 hp)
FC 302: 355–400 kW
(475–550 hp)
FC 102/FC 202: 560– 176F0254
630 kW (750–850 hp)
FC 302: 500–560 kW
(650–750 hp)
Danfoss A/S © 08/2014 All rights reserved.
®
VLT HVAC Drive FC 102
Disconnect fuses
176F0255
176F0256
Disconnect fuses
176F0255
176F0258
RFI RFI fuses
176F0257 176F0258
176F0257 176F0259
RFI RFI fuses
NA NA
NA NA
RFI disconnect
fuses
176F0260
176F0262
RFI disconnect
fuses
NA
NA
