Host Application Objects
12.6

EtherNet/IP Host Object (F8h)

Category
Basic, Extended
Object Description
This object implements EtherNet/IP specific features in the host application. Note that this object must not be
confused with the Ethernet Host Object, see
The implementation of this object is optional; the host application can support none, some, or all of the attrib-
utes specified below. The module will attempt to retrieve the values of these attributes during startup; if an at-
tribute is not implemented in the host application, simply respond with an error message (06h, "Invalid
CmdExt[0]"). In such case, the module will use its default value.
If the module attempts to retrieve a value of an attribute not listed below, respond with an error message
(06h, "Invalid CmdExt[0]").
Note that some of the commands used when accessing this object may require segmentation. For more infor-
mation, see Message Segmentation, p.
If the module is configured to use EIP QuickConnect functionality, the EDS file has to be changed. As the
EDS file is changed, the identity of the module has to be changed and the module will require certification..
See also ...
• Identity Object (01h), p. 75
• Assembly Object (04h), p. 79
• Port Object (F4h), p. 97
• CIP Port Configuration Object (0Dh), p. 145
• Anybus CompactCom 40 Software Design Guide, "Error Codes"
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Anybus CompactCom 40 EtherNet/IP Network Guide
Ethernet Host Object (F9h), p.
135.
(CIP object)
(CIP object)
(CIP object)
Get_Attribute
Process_CIP_Object_Request
Set_Configuration_Data
Process_CIP_Routing_Request
Get_Configuration_Data
Get_Attribute
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
169.
Value
"EtherNet/IP"
02h
0001h
0001h
160 (218)
