Host Application Objects
12.4

CIP Identity Host Object (EDh)

Category
Extended
Object Description
This object allows for applications to support additional CIP identity instances. It is used to provide additional
product identity information, e.g. concerning the software installed.
The first instance in the CIP identity object will not change its behavior. When implementing instances in the
CIP identity host object, they will be mapped to the CIP identity object starting at instance 2. Instance no. 1 in
the CIP identity host object will be mapped to instance no. 2 in the CIP identity object and so on.
See also ...
• Identity Object (01h), p. 75
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Instance Attributes (Instance #1)
# Name
1 Vendor ID
2 Device Type
3 Product Code
4 Revision
5
Status
6 Serial Number
7 Product Name
Anybus CompactCom 40 EtherNet/IP Network Guide
(CIP object)
Get_Attribute
Get_Attribute
Get_Attribute_All
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
Access Data Type
Get UINT16
Get UINT16
Get UINT16
Get struct of:
UINT8 Ma-
jor UINT8
Minor
Get UNIT16
Get UINT32
Get Array of
CHAR
Value
"CIP Identity"
01h
Depends on application
Depends on application
Description
These values replace the values for the CIP identity object in-
stance #2 and upwards.
See also...
Identity Object (01h), p. 75 (CIP-object)
