Anybus CompactCom 40 Network Manual page 67

JSON
ifcounters.json
GET network/ifcounters.json?port=<port>
Valid values for the argument <port> are 0, 1, and 2.
• Valid values for the argument <port> are 0, 1, and 2.
• Port number 0 option refers to the internal port (CPU port).
• Port number 2 option is only valid if two Ethernet ports are activated in the module.
Name
inoctets
inucast
innucast
indiscards
inerrors
inunknown
outoctets
outucast
outnucast
outdiscards
outerrors
Anybus CompactCom 40 EtherNet/IP Network Guide
Data Type Description
Number IN: bytes
Number IN: unicast packets
Number IN: broadcast and multicast packets
Number IN: discarded packets
Number IN: errors
Number IN: unsupported protocol type
Number OUT: bytes
Number OUT: unicast packets
Number OUT: broadcast and multicast packets
Number OUT: discarded packets
Number OUT: errors
65 (218)
SCM-1202-031 -EN 1.6
