Anybus Module Objects
Instance Attributes (Instance #20, QuickConnect)
This instance enables or disables the QuickConnect functionality from the application. Changes are valid
after reset or power cycle. The value of the QuickConnect attribute (#12) in the TCP/IP Interface object (F5h),
will change immediately.
This instance has no effect unless QuickConnect is enabled in the EtherNet/IP host object. If QuickConnect
is disabled in the EtherNet/IP host object the application is advised to hide this instance to the end-user.
See also...
• TCP/IP Interface Object (F5h), p. 99
• EtherNet/IP Host Object (F8h), p. 160
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Anybus CompactCom 40 EtherNet/IP Network Guide
Access Data Type Description
Get Array of "QuickConnect"
CHAR
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM If read, the actual value will be received. If written, the written val-
ue is reflected in attribute #6 until a reset.
Value:
00h
01h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value:
00h
01h
Meaning:
Disable (default)
Enable
Meaning:
Disable
Enable
