Anybus CompactCom 40 Network Manual page 115

Anybus Module Objects
Instance Attributes (Instance #6, DHCP Enable)
Value is used after module reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #7 Ethernet Communication Settings 1)
Changes have immediate effect.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
Anybus CompactCom 40 EtherNet/IP Network Guide
Access Data Type Description
Get Array of "DHCP"
CHAR
(Multilingual, see page 119)
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset.
(Multilingual, see page 119)
Value
00h
01h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value
00h
01h
Access Data Type Description
Get Array of "Comm 1"
CHAR
(Multilingual, see page 119)
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM Value
00h
01h
02h
03h
04h
Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value
00h
01h
02h
03h
04h
String Meaning
"Disable" DHCP disabled
"Enable" DHCP enabled (default)
String Meaning
"Disable" DHCP disabled
"Enable" DHCP enabled
String Meaning
(Multilingual, see page 119)
"Auto" Auto negotiation (default)
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
String Meaning
(Multilingual, see page 119)
"Auto" Auto negotiation
"10 HDX" 10Mbit, half duplex
"10 FX" 10Mbit, full duplex
"100HDX" 100Mbit, half duplex
"100FX" 100Mbit, full duplex
113 (218)
SCM-1202-031 -EN 1.6
