Host Application Objects
Command Details: Get_Attribute_All
Category
Extended
Details
Command Code:
Valid for:
Description
This service must be implemented by the application for all instances that exist in the CIP identity host object.
If identity data is requested from the network the Anybus module will issue this command to the application.
The application will then respond with a message containing a struct of all attributes in the requested
instance.
• Command Details
(no data)
• Response Details
Field Contents
Vendor ID
MsgData[0,
1]
MsgData[2, Device type
3]
MsgData[4, Product code
5]
MsgData[6] Major revision
MsgData[7] Minor revision
MsgData Status
[8,9]
MsgData[10 Serial number
.. .13]
MsgData[14 Product name
.... n]
Anybus CompactCom 40 EtherNet/IP Network Guide
10h
Object
Comments
ABCC CIP identity data
