Anybus CompactCom 40 Network Manual page 164

Host Application Objects
# Name
14 Listen-Only heart-
beat instance
number
15 Assembly object
Configuration in-
stance number
16 Disable Strict IO
Match
17 Enable unconnected
routing
18 Input-Only extended
heartbeat instance
number
19 Listen-Only extended
heartbeat instance
number
20 Interface label port 1
21 Interface label port 2
22 Interface label inter-
nal port
23
(reserved)
-
25
26 Enable EtherNet/IP
QuickConnect
27 (reserved)
-
28
29 Ignore Sequence
Count Check
30 ABCC ADI Object
Number
31 Enable DLR
Anybus CompactCom 40 EtherNet/IP Network Guide
Access Data Type Default
Value
Get UINT16 0004h
Get UINT16 0005h
Get BOOL False
Get BOOL False
Get UINT16 0006h
Get UINT16 0007h
Get Array of Port 1
CHAR
Get Array of Port 2
CHAR
Get Array of Internal
CHAR
Get BOOL False
Get BOOL False
Get UINT16 00A2h
Get BOOL True
Comment
See "Instance 04h Attributes (Heartbeat, Listen-Only)"
in Assembly Object (04h), p. 79
See "Instance 05h Attributes (Configuration Data)" in
Assembly Object (04h), p. 79
If true, the module will accept Class1 connection re-
quests that have sizes that's less than or equal to the
configured IO sizes.
If true, the module enables unconnected CIP routing.
This also triggers an initial upload of the contents of the
CIP Port Mapping object.
See "Instance 06h Attributes (Heartbeat, Input-Only Ex-
tended)" in Assembly Object (04h), p. 79
See "Instance 06h Attributes (Heartbeat, Listen-Only
Extended)" in Assembly Object (04h), p. 79
object).
The value of this attribute is used to change the inter-
face label for Ethernet Link Object Instance #1
The value of this attribute is used to change the inter-
face label for Ethernet Link Object Instance #2
The value of this attribute is used to change the inter-
face label for Ethernet Link Object Instance #3
Value Meaning
True EtherNet/IP QuickConnect functionality
enabled.
False False EtherNet/IP QuickConnect function-
ality disabled.
If the module is configured to use EIP QuickConnect
functionality, the EDS file has to be changed. As the
EDS file is changed, the identity of the module has to
be changed and the module will require certification.
Setting this attribute to "true" makes the module ignore
the Sequence Count Check for consumed Class 1 data.
This means that all data, not just changed/new data, re-
ceived from the Originator, will be copied to the applica-
tion. Copying all data and not just changed data is a
violation of the CIP specification. It will also affect the
performance of the module.
Use precaution when setting this flag to"true".
HMS Industrial Networks AB will do NO performance
measurements and states NO guarantees about how
performance will be affected when copying all data.
This attribute either changes the object number of the-
ADI Object (CIP object) or disables the ADI Object (CIP
object). Valid object numbers are within the vendor spe-
cific ranges (0064h - 00C7h and 0300h - 04FFh). Any
other value will disable the ADI object.
Value Meaning
True DLR functionality enabled
False DLR functionality disabled
162 (218)
(CIP-object).
(CIP-object).
(CIP-object).
(CIP-
SCM-1202-031 -EN 1.6
