Appendix G: Backward Compatibility
G.4 Network Specific — EtherNet/IP
G.4.1 Network Object (03h)
Attribute #1, Network
Type
Value
0085h
009Ch
009Bh
00ABh
G.4.2 EtherNet/IP Host Object (F8h)
Attribute
#2, Device
Type
#3, Product
Code
#6, Product
Name
Attribute
#27, Produc-
ing Instance
Map
Attribute
#28, Con-
suming In-
stance Map
Anybus CompactCom 40 EtherNet/IP Network Guide
The 30-series module is available in two network type versions, either with
"Beacon based DLR" (Highest performance) or with "Announce based DLR"
which both are Ethernet redundancy protocols. The 40-series is only available
with "Beacon based DLR". The network type value differs between the versions.
Network Type
EtherNet/IP, No DLR
EtherNet/IP, Announce Based DLR
EtherNet/IP, Beacon Based DLR
EtherNet/IP, Beacon Based DLR +
IIoT
Default Anybus CompactCom
Product
0000h 30-series, EtherNet/IP,
No DLR
0000h 30-series, EtherNet/IP,
Announce Based DLR
002Bh 30-series, EtherNet/IP,
Beacon Based DLR
002Bh 40-series, EtherNet/IP,
Beacon Based DLR
0063h 30-series, EtherNet/IP,
No DLR
002Eh 30-series, EtherNet/IP,
Announce Based DLR
0036h 30-series, EtherNet/IP,
Beacon Based DLR
0037h 40-series, EtherNet/IP,
Beacon Based DLR
Anybus-CC EtherNet/IP 30-series, EtherNet/IP,
No DLR
CompactCom EtherNet/ 30-series, EtherNet/IP,
IP(TM) 2P Announce Based DLR
Anybus-CC EIP (2-Port) 30-series, EtherNet/IP,
BB DLR Beacon Based DLR
Anybus CompactCom 40 40-series, EtherNet/IP,
EtherNet/IP(TM) Beacon Based DLR
See comment
See comment
Anybus CompactCom Product
30-series 1-port
30-series 2-port
30-series and 40-series
40–series
Comment
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
Attribute removed in the 40-series
(only available in the 30-series Ether-
Net/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functional-
ity in the Assembly Mapping Object
(EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
Attribute removed in the 40-series
(only available in the 30-series Ether-
Net/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functional-
ity in the Assembly Mapping Object
(EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
