Appendix B: Implementation Details
B Implementation Details
B.1 SUP-Bit Definition
The supervised bit (SUP) indicates that the network participation is supervised by another net-
work device. In the case of EtherNet/IP, this means that the SUP-bit is set when one or more
CIP (Class 1 or Class 3) connections has been opened towards the module.
B.2 Anybus State Machine
The table below describes how the Anybus Statemachine relates to the EtherNet/IP network
Anybus State
WAIT_PROCESS
ERROR
PROCESS_ACTIVE
IDLE
EXCEPTION
B.3 Application Watchdog Timeout Handling
Upon detection of an application watchdog timeout, the module will cease network participation
and shift to state EXCEPTION. No other network specific actions are performed.
Anybus CompactCom 40 EtherNet/IP Network Guide
Implementation
The module stays in this state until a Class 1
connection has been opened.
Class 1 connections errors
Duplicate IP address detected
Error free Class 1 connection active (RUN-bit
set in the 32-bit Run/Idle header of an Exclu-
sive-Owner connection)
Class 1 connection idle.
Unexpected error, e.g. watchdog timeout etc.
174 (218)
Comment
-
-
Only valid for consuming connections.
MS LED turns red (to indicate a major
fault)
NS LED is off
