Hardware Monitoring (The Winbond Hardware Doctor Utility)

Appendix G. Hardware Monitoring (The Winbond
The Winbond Hardware Doctor is a self-diagnostic system for PCs used with Winbond W83627HF
chipset. It protects PC hardware by monitoring several critical items including power supply voltages,
CPU & system fan speeds and CPU and system temperatures. These items are important for the system
operation. Errors may result in permanent damage to the PC. Once any item is out of its normal range, a
warning message pops up reminding you to take proper measures.
The installation procedures and screen shots in
this chapter are based on Windows XP
operating system. Please follow the on-screen
instruction for those of other operating system.
Insert the Installation Disk into CD-ROM drive,
it should execute the installation program
automatically. If not, double-click the execution
file at the main directory of this Installation
Disk to enter the installation menu.
Click "Utility".
1.
2. Click "Winbond Hardware Doctor".
Hardware Doctor Utility)
Click "Next >".
3.
Click "Next >".
4.
