Introduction

Chapter 1. Introduction

1-1. Features and Specifications

1. CPU
!
Supports Intel Pentium
!
400MHz/533MHz System Data Bus
2. Chipset
!
Intel 82845E (MCH) + 82801DB (ICH4)
!
Supports AGP 4X 1.5V device only
!
Supports Ultra ATA/100/66/33 mode
3. Memory
!
Three 184-pin DIMM sockets (unbuffered Non-ECC DIMM)
!
Supports 3 DIMM DDR 200/266 (Max. 2GB)
!
Do not supports the mixed use of ECC and non-ECC RAM
4. Serial ATA
!
On board 2-Channel Serial ATA interface of 1.5 G bps
5. ATA133 RAID
!
HighPoint HPT374 IDE controller
!
Supports Ultra ATA 133MB/sec data transfer rate
!
Supports RAID 0 (Stripping mode for boosting performance) mode
!
Supports RAID 1 (Mirroring mode for data security) mode
!
Supports RAID 0+1 (Stripping and Mirroring) mode
6. Media XP (Optional)
!
Supports memory card (MS or SD) Interface
!
Supports Compact Flash ROM Interface
7. Audio
!
Realtek ALC650 (AC-Link)
!
Supports 6 Channel CODEC for AC3 5.1 Channel purpose
!
Professional digital audio interface supporting 24-bit S/PDIF out
8. USB 2.0
!
10 x USB 2.0 ports
9. IEEE 1394
!
3 x IEEE 1394 ports
10. LAN
!
Onboard RTL8100B 10/100M PCI Fast Ethernet Controller
®
4 socket 478 processor
1-1
User's Manual
