Hardware Setup
(17).
D17/D18: Status Indicator
•
D17 (5VSB): Stand By LED Indicator
This LED lights up when the power supply is connected with power source.
•
D18 (VCC): Power on Indicator
This LED lights up when the system power is on.
(18).
J3/J4: Serial ATA Connector
These two connectors are provided to attach one serial ATA device at each channel through Serial ATA
cable.
2-17
User's Manual
