BIOS Setup 3-19
wake-up your computer by PCI devices. For instance, if you had installed a PCI LAN card with Wake-Up
on LAN capability, then you could wake-up your computer from another computer via a network by
sending a wake-up frame signal. This feature also allows the PCI card built-in hardware function to
support the wake up function without special cables connected to the motherboard.
NOTE: This feature needs a specific network interface (optional). Also your ATX power supply +5V
standby power must be at least 720mA compatible.
Power On by Ring:
Two options are available: Enabled and Disabled. Default setting is Disabled. If you connect an external
modem to the onboard serial port, the system will be turned on when a telephone ring-up occurs.
Resume by Alarm:
Two options are available: Enabled and Disabled. Default setting is Disabled. The RTC alarm can turn on
the system. You can set Date (of month) and Time (hour, minute, and second) when you set this item to
Enabled.
Green PC LED Status:
This option selects the lighting status of the Suspend mode. The options are: Off and Blinking. The
default setting is Blinking.
