SIP ID:
• It is the user part of the full SIP URI. This can be a number or text.
Maximum 24 characters including all ASCII characters. Blank is not
supported. By default, '*' for each SIP Account.
For example:
• A full SIP URL provided by the ITSP is 12345@abc.com than
program 12345 in this field.
• When a caller calls this number, the call lands on the Network port
and is routed as per the Call Routing Option assigned to the SIP
Account.
• When an OG call is made through a SIP Account with SIP ID;
SIP:12345@abc.com, SIP:12345@abc.com and the FXS port
name are also sent in the SIP message. This helps the callee to
identify the caller. This is because many ports may use the same
SIP Account to make an OG call.
• Refer Note 3 and 4 at the end of chapter.
Registrar Servers' Address:
• Enter here the address of the SIP Registrar. It can be IP address
also.
• Maximum 40 characters including extended ASCII characters.
• Default = Blank.
• Refer Note 2 at the end of chapter.
Registrar Servers' Port:
• Enter the Registrar Server's listening port number for SIP. SE may
change this field if the ITSP provides a SIP port number other then
the default.
• This may be same as SIP Server's Port address.
• Range = 1024-65535.
• Default = 5060.
Re-Registration Timer:
• As a part of normal process, the Register server deletes an entry of
its client from its database on expiry of a fixed timer.
• Thus, this timer sets period for how long an entry remains
registered with the Register Server.
• This timer is used as Expire timer when message is sent for
