TRBOnet Configuration

This section describes how to configure TRBOnet software so that the operator could
see and manage the physical I/O pins of the A200 gateway. In the example below, the
A200 gateway is connected to a MOTOTRBO radio through USB and has three input
pins and two output pins connected to external hardware (Figure 16).
In the A200 gateway configuration, the physical I/O pins are mapped to the logical
pins of TRBOnet (Figure 17).
To complete the I/O pin configuration in TRBOnet, read the following sections:
4.1 TRBOnet Enterprise/PLUS Configuration

4.2 TRBOnet Watch Configuration

22
Figure 16: Connected I/O pins
Figure 17: Pin configuration
